Product Overview

The Balboa BP200UX 3.0KW PCB is a top-of-the-line circuit board designed to breathe new life into your BP200 control box. Manufactured by Balboa Water Group, a leader in the spa industry, this PCB ensures optimal performance and reliability for your hot tub system.

Key Features

Versatile Pump Control: Manages single or dual-speed pumps, including a circulation pump if needed
Multiple Pump Support: Controls up to three pumps for ultimate customization
Air Blower Compatibility: Optional air blower control for enhanced hydrotherapy
Powerful Heating: Integrated 3kW heater control for maintaining perfect water temperature
Ozone Support: Manages an ozone generator for improved water purification
Lighting Control: Operates a 10V light (1amp Max) for creating the right ambiance
Entertainment Ready: Includes a point for radio, TV, or AV integration
WiFi Capability: Designed to work with a WiFi receiver for convenient iPhone operation

Compatibility and Integration

The BP200UX PCB is specifically designed for use with the BP200 control box. It seamlessly integrates with Balboa’s serial standard TP range of topside controls, including popular models like the TP900, TP800, TP600, and TP400. This compatibility ensures a smooth upgrade or replacement process for your existing system.

Technical Specifications

Specification	Detail
Type	PCB (Printed Circuit Board)
Manufacturer	Balboa Water Group
Voltage	230V
Frequency	50Hz
Heater Power	3kW
Pump Support	Up to 3 pumps
Light Output	10V @ 1amp Max
WiFi Ready	Yes
